SKY WiFi + RF Dimmer/CCT Receiver, 2 Ch 5A, Tuya, Alexa & Google
- Free shipping on orders $200+
- Free store pickup · Hialeah, FL
- Same-day shipping on stock items
- 2-in-1 WIFI & Radio Frequency Communication System.
- Works with any 12 or 24 VDC power supply.
- Pair it up with any LED dimmer or CCT controller.
- 5 Channels (RED, GREEN, BLUE, WARM WHITE, COOL WHITE).
- Maximum current: 15A (3 per Channel).
- DIM (Single Color) Rated Power: 120W/12V , 240W/24V.
- CCT Rated Power: 120W/12V , 240W/24V.
- Compatible with SKY Hand held remotes not included.
- Works on the 433.92 Mhz RF band.
- Compatible with smart phone app name “TUYA”.
- Compatible with Alexa, and google home.
Related linear lighting components frequently needed:
LED Strips
Wet Rated LED Strips
Power Supplies
Aluminum Channels
Guaranteed Safe Checkout
Description
- 2-in-1 WIFI & Radio Frequency Communication System.
- Works with any 12 or 24 VDC power supply.
- Pair it up with any LED dimmer or CCT controller.
- 5 Channels (RED, GREEN, BLUE, WARM WHITE, COOL WHITE).
- Maximum current: 15A (3 per Channel).
- DIM (Single Color) Rated Power: 120W/12V , 240W/24V.
- CCT Rated Power: 120W/12V , 240W/24V.
- Compatible with SKY Hand held remotes not included.
- Works on the 433.92 Mhz RF band.
- Compatible with smart phone app name “TUYA”.
- Compatible with Alexa, and google home.
Related linear lighting components frequently needed:
LED Strips
Wet Rated LED Strips
Power Supplies
Aluminum Channels
Specifications
Physical Characteristics
Length8 in
Width5 in
Electrical Characteristics
Input Voltage12/24VDC
Output Voltage12/24VDC / Same as Input voltage
Current Per Channel5A
Rated Current10A
Recommended Power LimitRGB: 108W/12V, 216W/24V || RGBW: 144W/12V, 288W/24V || RGBCCT: 180W/12V, 360W/24V
Input ConnectorBlock Terminals
Control & Compatibility
Remote ControllerNo Included, Sold Separately
Controllable ByAPP "TUYA" / Remote Control (not Included)
DimmableBy Remote Controller
Control Distance30 Meters, 100 feet
Compatible Mobile App(S)TUYA
Certifications & Ratings
Warranty2 Years
General Information
FinishWhite
ConnectionScrew Terminal Block Connector
Height2 in
Mounting TypeScrew-Ready Brackets on Edges
BrandSKYDANCE
Product TypeController
Channels2 Channels (WW & CW)
Number of Outputs1
Output ConnectorBlock Terminals
