SKY RF RGB/RGBW Receiver, 4 Channels 5A, 12/24V, Sync Function

  • Envío gratis en pedidos de $299+
  • Retiro gratis en tienda · Hialeah, FL
  • Envío el mismo día en productos en stock

SKY RF RGB/RGBW receiver, 4 channels at 5A each, sync function. 180W/12V or 360W/24V rated for RGB use, 240W/12V or 480W/24V for RGBW use; pairs with either RGB or RGBW strips and low-voltage units. 2-year warranty.

  • Radio Frequency Communication System.
  • Works with any 12 or 24 VDC power supply.
  • Pair it up with any LED RGB strips & low voltage units, and RGBW strips & low voltage units.
  • 3 Channels (RED, GREEN & BLUE).
  • Maximum current: 20A (5 per Channel).
  • RGB Rated Power: 180W/12V , 360W/24V.
  • RGBW Rated Power: 240W/12V , 480W/24V.
  • Hand held remote not included included.
  • Works on the 433.92 Mhz RF band.
  • Receiving device can be sync to a maximum of 10 hand held remotes.
  • Hand held remote can be synced to unlimited receiving devices of the same model.

Guía de compra: Guía de controladores LED →

VisaMastercardAmex

Pago Seguro Garantizado

SKU:ECTSK-RFRC4C5A
Categorías:LED Controllers, MULTICOLOR, HAND HELD REMOTE CONTROL

Descripción

SKY RF RGB/RGBW receiver, 4 channels at 5A each, sync function. 180W/12V or 360W/24V rated for RGB use, 240W/12V or 480W/24V for RGBW use; pairs with either RGB or RGBW strips and low-voltage units. 2-year warranty.

  • Radio Frequency Communication System.
  • Works with any 12 or 24 VDC power supply.
  • Pair it up with any LED RGB strips & low voltage units, and RGBW strips & low voltage units.
  • 3 Channels (RED, GREEN & BLUE).
  • Maximum current: 20A (5 per Channel).
  • RGB Rated Power: 180W/12V , 360W/24V.
  • RGBW Rated Power: 240W/12V , 480W/24V.
  • Hand held remote not included included.
  • Works on the 433.92 Mhz RF band.
  • Receiving device can be sync to a maximum of 10 hand held remotes.
  • Hand held remote can be synced to unlimited receiving devices of the same model.

Especificaciones

Physical Characteristics

Length8 in
Width5 in

Electrical Characteristics

Input Voltage12/24VDC
Output Voltage12/24VDC / Same as Input voltage
Current Per Channel5A
Rated Current20A
Recommended Power LimitRGB: 180W/12V, 360W/24V || RGBW: 240W/12V, 480W/24V.
Input ConnectorBlock Terminals

Control & Compatibility

Remote ControllerNo Included, Sold Separately
Controllable ByRemote Control (not Included)
DimmableBy Remote Controller
Control Distance30 Meters, 100 feet

Certifications & Ratings

Warranty2 Years

General Information

FinishWhite
Channels3 Channels (RGB) / 4 Channels (RGBW)
ConnectionScrew Terminal Block Connector
Height2 in
Mounting TypeScrew-Ready Brackets on Edges
BrandSKYDANCE
Number of Outputs1
Output ConnectorBlock Terminals
